How to draw a pitched roof or a gable roof?

Homestyler Official20 February 2021

Switch to the "RCP" view (means Reflected Ceiling Plan; shortcut key:2) in the bottom left corner to enter the top view. Select the top surface and click "Customize Ceiling" to enter the ceiling interface. (or you can also click "Customize-Customize Ceiling" from the left catalog and select the top surface to enter the ceiling interface). Select gable roof or pitched roof from "Ceiling-Parametric Ceiling-Other" on the left and drag it into the room. The ceiling will be automatically applied to the room, and you can adjust the parameter of rotation angle, slope, the size of the ceiling from the right property panel.


0 2093 5

Comments(5)

head-img
Ayden Grace27 May
But here the roof is below the ceiling. How do I raise it?
8 Reply
head-img
Kaito Liscombe6hr
You make your wall height larger under wall settings!@ Ayden Grace
But here the roof is below the ceiling. How do I raise it?
Helpful Reply
head-img
jerlinginteriors21 August
Did you get itvright? I am also struggling with that, my top ceiling does not want to dissappear
Helpful Reply
head-img
Anastassia Anastassia7 August
How to make windows in the roof?
Helpful Reply
head-img
Meredith W3 June
https://www.youtube.com/watch?v=4wG717xhzkg@ Ayden Grace
But here the roof is below the ceiling. How do I raise it?
Helpful Reply
